Bộ phân ly đo áp suất P10038A-01

Analog Input, 8AIxTC Module đầu vào cặp nhiệt độ	SM 1231, AI 8x16bitTC Supply voltage: 24Vdc Input current: 40 mA (Current consumption, typ.); 80mA (from backplane bus 5 V DC, typ.) Number of analog inputs: 8 (Current or voltage differential inputs) Input ranges: Voltage (±10V, ±5V, ±2.5V); Current (4 to 20 mA, 0 to 20 mA) Resolution with overrange (bit including sign), max: 15 bit; + sign Dimensions: (WxHxD=45x100x75mm) Refer: 6ES7231-5QF32-0XB1 Manufacturer: Siemens .
Weight Indicator for cement tank (range: 0 -> 100000 kg) Thiết bị hiển thị tải trọng bồn xi măng, dải làm việc từ 0 – 100000 Kg	8-1/2″” gauge, inner 400 kgs sub., outer 200 kgs sub., 2×1 ratio, Range: 0 -> 100000 kg Refer: WG 801-41 Manufacturer: Wagner
Weight Indicator for cement tank (range: 0 -> 4500 kg) Thiết bị hiển thị tải trọng bồn xi măng, dải làm việc từ 0 – 4500 Kg	8-1/2″ gauge, inner 25 kgs sub., outer 12.5 kgs sub., 3×1 ratio, Range: 0 -> 4500 kg Refer: WG 801-154 Manufacturer: Wagner
Tension Load cell 08 Sq.in Cảm biến đo tải trọng_TeiriogaT^LiHK	Effective Area: 8.0 sq. in. aluminum tension load cell Max Capacity: 4000 LBS Diaphragm/Seal Kit: CD268-2 8.0 Tension Load Cell Crow Oilfield CTC 104
Diaphragm area 08 Sq.in Màng ngăn thay thế 8 inch vuông của cảm biến Wireline Load Cell	Rubber diaphragm suitable for tension load cells, with 8.0 square inch effective area. Refer: CD268-2 Manufacturer: Crow Oilfield .
Deapth transmitter with 10m of cable Cảm biến đo mức nước tank 10 mét nước , đường kính 0.69 inch	±0.10% FS BSL accuracy standard, ±0.06% FS BSL available Fully welded 17.5 mm (0.689 inch) diameter titanium construction Output signal: 4 to 20mA (2-wire) Long-term stability: ±0.1% FS per annum Temperature compensated from -2 to 30°C (28 to 86°F) Refer: Druck PTX 1830
Wind speed and direction Indicatior + Sensor Cảm biến Sato 7790-00	Wind Direction: Maximum Tolerable Speed: 90 m/s Wind Speed Type: Rectified Voltmeter Wind Direction Mechanism: Synchro Motor Measurement Range: 2m/sto 60 m/s Wind Direction: 360° Accuracy: Wind Speed: ±0.5 m/s under 10m/s ±5% over 10 m/s Wind Direction: ±5° Power Requirements: 100 VAC (50/60 Hz) ±10% Sato 7790-00
Expansion module board for barit tank monitoring system Bo hiển thị mức tank ba-rit	Expansion module board for barit tank monitoring system. Power:+5VDC, +12VDC. Socket 25 pin: 07pcsHD74LS138: 01pcs. SN74LS245N: 03 Reference by Code: hD74LS138- SN74LS245N
PLC signal – LED converter for barit tank Bo chuyển đổi tín hiệu PLC tank ba-rit sang LED	Module board convert PLC output signal to Led display board input signal. INTEL 1980 controler. Power supply: +12 VDC Refer: sCN8031HCCN40: MBM 2764-30-AKM6264- 10
Expansion module board for ballast tank monitoring system Bo hiển thị mức tank dầu nước	Module board demux input signal to multi display channels for ballast tank monitoring system. Power:+5VDC, +12VDC. Socket 25 pin: 07pcs. Refer: HD74LS138- SN74LS245N-B
PLC signal – LED converter for ballast tank Bo chuyển đổi tín hiệu PLC tank dầu nước sang LED	Module board convert PLC output signal to Led display board input signal. Intel 1980 controler. Reference by Code: SCN8031HCCN40-MBM 276430- AKM6264-10-B
Power Supply for Display Bộ nguồn cho bảng hiển thị (Loại lớn , đang dùng)	Power supply for computer. Min power : 1600W. Min current: 4A. Out put: 5 V and 12V and 24V. Refer: CPL-GOlD 1600W Manufacturer: Gold .
Bộ đo tải trọng Wagner WCC103	Range 0-100.000Kg(100 ton), Ratio 2:1, Pressure 02205 Psi, Diaphragm: area 50 sq in, gap 19mm Wagner WCC103
Diaphragm for 50.0 square inch effective area compression load cell Màng cao su cảm biến đo tải trọng	Rubber diaphragm suitable for compression load cells, with 50.0 square inch effective area; gap 19 mm Refer: CD206 Manufacturer: Crown Oildfield .
Hunt Blower Assembly for mud pump Cụm quạt gió 752-15CCW-36460	Include (Blower Wheel ASM; Blower Housing ASM; Electric Motor and Rainhood ASM) Wheel size: 16.75 inch Airflow: 3000 (SCMF) 3-Phase motor Spec 2970, c/w AC Motor Voltage: 230/460 Vac 60Hz Power: 15 HP Speed: 3450 Rpm Frame: 254 T Refer: 752-15CCW-36460 Manufacturer: Hunt Engine .
Hunt Blower assembly for Drawwork Cụm quạt gió 752-10CCW-36460	Include (Blower Wheel ASM; Blower Housing ASM; Electric Motor and Rainhood ASM) Wheel size: 16.75 inch Airflow: 3000 (SCMF) 3-Phase motor Voltage: 230/460 Vac 60Hz Power: 10 HP Speed: 3450 Rpm Frame: 215T Spec 2826 Refer: 752-10CCW-36460 Manufacturer: Hunt Engine .
DC Motor Carbon Brushs Chổi than 41B537963P01	Electrographitic Thickness 3/4″ Width 2 1/4″ Length 2″ Refer: 41B537963P01 (Oldcode)/493X317P06 Manufacturer: NOV .
Module, Metering Output Bo mạch cung cấp tín hiệu 2032568-6	The Metering Interface Module contains six (6) meter amplifier channels. Independent Gain and Offset adjustments are provided for each. The six channels are designated “A” through “F”. Channels “C” and “F” are made to provide 420mA powered outputs at up to 10V burden. The other outputs are designed to provide 0-10V output. The metering channel gain adjustment range allows for signals with between 4.0 and 9.0 Volts full scale to give full scale output (20mA or 10V). Refer: 2032568-6 Manufacturer: NOV .
Hub motor (for mud pump and drawwork) Khớp nối trục động cơ tời khoan	Hub: Oilfield GE752 standard tapered bore (The standard hub for GE752 motor) 9.120 IN OD, Power take – off Refer: 493A471P1 Manufacturer: NOV .
Limit Switch Công tắc giới hạn_KoimeBoH BBiK.noaaTe.iB	Limit Switch Spring Return : Div 1 Class I Groups B, C, D Class II Groups E, F, G : 1-N.O. 1-N.C. Ui rated insulation voltage: 250Vac Ith continuous thermal current: 10A Refer: CR53N2 Manufacturer: Schneider .
Displacement Probe Sensor Cảm biến tay gạt điều khiển phanh điện từ tời khoan INA-081/3/070/50/0/204	Sensor axis: 1 Measurement: Vibration displacement Transducer type: Eddy current Maxdisplacement(mm): 1.5 Connector type: Integrated cable Refer: INA-081/3/070/50/0/204 9(80002644)) Manufacturer: Bruel & kier Vibro GmbH Germany .
AC Motor Động cơ điện	Voltage: 460 Vac; 60 Hz; Power active: 93Kw; Current rating: 141 A; Speed: 1750 Rpm, 3 phase Refer: LVC444TTFS6036DVR47I Manufacturer: Marathon .
Torgue gauge Đồng hồ mô men người máy vặn cán 10035453-001	Model: 10035453-001 TORGUEGAUGE 15000KG-M 100KG-MDIV 1000 LB-FTDIV 110000 LB-FT CAL.PRESS 2750 F/S CALIB:3000PSI Refer: MFG P/N: 82310-500 Manufacturer: NOVMD TOTCO
Electronic Control Module (ECM) Bộ điều khiển điện tử của động cơ 478-7933	ECM (Electronic Control Unit) include Program config with engine model C15 Refer: 478-7933 Manufacturer: Caterpillar .
Micro motion signal processing device Đáu đọc tín hiệu từ bộ đo coriorlis	Signal processing device compatibility Emerson’s Micro Motion 2700 Coriolis meters. Require : ver 2.5 TYPE 700 Manufacturer: Emerson .
Control Processor (32K memory) Bộ vi xử lý điều khiển máy bơm trám xi măng	32K Memory, Ethernet & RS-232 Communication Ports (Including Software and Program for Compact Twin cementing unit-Zone II model: SK-CTCU-ASDCS-TWS600S-1000D) Refer: TZP-314-E7-3 Manufacturer: Techzone .
Tension Load Cells 6.53 sq. inches Cảm biến lực CTC107	Effective Area: 6.53 sq. in. tong sensor Max Capacity: 25000 lbs Refer: CTC107 Manufacturer: Crown Oilfield .
Tension Load Cells 4.0 sq. inches Loadcell đo momen 4 inch	Tension Load cell 4.0 In2 Reference by Code: CTC106 or equipvalent Manufacturer: CROWN OILFELD
RPM Indicator Đồng hồ hiển thị tốc độ vòng quay	Electric tacho metter input: 0-10VDC Dia: 5 inch Panel mount Range: 0 -> 300 RPM Refer: PR21A-13 Manufacturer: NOVMD TOTCO .
Topdriver Moment Indicator Đồng hồ hiển thị mô men của máy khoan đỉnh cán	Electric torque metter input: 0-10VDC Dia: 5 inch Panel mount Range: 0-60.000 lb.ft Refer: GHT102A-00496 Manufacturer: NOVMD TOTCO .
Piston Separator Bộ phân ly đo áp suất P10038A-01	Pistion separator, 1:1, W/nut & bw sub, Maxpressure: 15Kpsi. Refer: P10038A-01 Manufacturer: NOVMD TOTCO .
Tong line pull gauge 0-25.000 Lbs Đồng hồ đo CG600-423	Tong line pull gauge Dia : 6 inch Box mount Dual scale : 0-25.000Lbs/0-11.000KG Compatable with 6.53 inch2 tension loadcell Liquid filled Refer: CG600-423 (CR15765) Manufacturer: Crown Oilfield .
Tong line pull gauge 0-10.000 Lbs Đồng hồ mô men 0-10.000 Lbs	Tong line pull gauge Dia : 6 inch Box mount Dual range : 0 -4500 Kg & 0-10000 lbs Compatable with 4.0 inch2 tension loadcell Liquid filled Refer: CR17828 (or 19141) Manufacturer: Crown Oilfield .
Extension Panel Card mở rộng	Module extend quantity of camera channel Suitable with HSS05 system RevK Refer: 095517 Manufacturer: HERNIS .
Switch 8×8 Bộ chia tín hiệu điều khiển	Module demux control signal to each camera channel Suitable with HSS05 system RevK Refer: 095415/101825 Manufacturer: HERNIS .
Power card Bo mạch nguồn cho hệ thống Camera	Power supply for HSS05 system Suitable with HSS05 system RevK Input :110-240 VAC – 50/60 Hz Output: 5C-3A Model :TMS 15105 Refer: 095414 Manufacturer: HERNIS .
Control Board for Camera Bo mạch điều khiển camera	Control board for Hernis camera station Suitable with HSS05 system RevK Input: 20-30 VAC Output: 3-24 VDC Refer: 092289 Manufacturer: HERNIS .
Pressure gauge 0 – 700 Bar (Diameter 63mm, 1/4″NPT) Đồng hồcơ 0 – 700 Bar	Diameter: 63 mm, range 0 – 700 Bar, Connection: 1/4″ NPT, Material: 304SS orhigher, Dual scale (Bar-Psi), lower mount, liquid filled Refer: 230.50.063 Manufacturer: Wika .
Pressure Gauge 0 – 400 Bar (Diameter 160mm, 1/2″NPT) Đồng hồcơ 0 – 400 Bar	Diameter: 160 mm, range 0 – 400 Bar, Connection: 1/2″ NPT, Material: 304SS or higher, Dual scale (Bar-Psi), lower mount,liquid filled Refer: 233.50.160 Manufacturer: Wika .
Pressure Gauge 0-16 Bar (Diameter 63mm, 1/4″NPT) Đồng hồ cơ 0-16Bar	Diameter: 63 mm, range 0-16 Bar, Connection: 1/4″ NPT, Material: 304SS orhigher, Dual scale (Bar-Psi), lower mount, liquid filled Refer: 233.50.063 .
Pressure Gauge 0-16 Bar (Diameter 100mm, 1/2″NPT) Đồng hồcơ 0 – 16 Bar	Diameter: 100 mm, range 0-16 Bar, Connection: 1/2″ NPT, Material: 304SS orhigher, Dual scale (Bar-Psi), lower mount,liquid filled Refer: 233.50.100 16 Manufacturer: Wika .
Pressure Gauge 0-10 Bar (Diameter 63mm, 1/4″NPT) Đồng hồ áp suất	Diameter: 63 mm, range 0-10 Bar, Connection: 1/4″ NPT, Material: 304SS orhigher, Dual scale (Bar-Psi), lower mount,liquid filled Refer: 233.50.063 Manufacturer: Wika .
Pressure Gauge 0-7 Bar (Diameter 160mm, 1/2″NPT) Đồng hồcơ 0 -7 Bar	Diameter: 160 mm, range 0-7 Bar, Connection: 1/2″ NPT, Material: 304SS orhigher, Dual scale (Bar-Psi), lower mount, liquid filled Refer: 233.50.160 Manufacturer: Wika .
Top Hot Plate Mâm nhiệt của bếp	Dimension: 300 x 300 x43 (mm) Wattage: 3000 W Voltage: 440V Connection Type: Screw Refer: 405100003 Manufacturer: Aluminox .
Heat-resistant electrical cable Cáp điện có vỏ chịu nhiệt	Electrical Cables for Oven, heat-resistant and Fireresistant, 1 core ; 1.5 mm2 Refer: 610000019
Switch 4D-16A Công tắc lựa chọn số của bếp điện	Input Voltage: 440V; 3 phase; 60 Hz Maximum Current: 16A Four Position The switch has a 360o rotation Refer: 404100004 Manufacturer: Aluminox .
Thermostat (50-300oC) Bộ điều chỉnh nhiệt độ	Temperature range: 50-300oC Accuracy:±3 Switch type: normally closed Voltage: 250Vac Power: 16A Sensor size: 73 * 4mm Material: plastic, ceramic, Metal Refer: Model F50 – 300 PN:408100002 Manufacturer: Aluminox .
Heating Element (440V, 2kW) Điện trở đun	Dimension: 640 x 460 mm Voltage: 440 V Power: 2Kw Refer: 180342 Manufacturer: Electrolux .
Exit Lighting, C/w Battey for 3 hours Đèn chỉ dẫn lối thoát hiểm	Main Supply: 110VAC 50/60Hz Power Consumption: 4W Battery: High temperature NIMH battery Charging Monitor: Green LED Recharge Period: 24 hrs Testing Facility: Test-switch for independent testing Emergency Duration: 3 hrs Safety Feature: Low-voltage cut-off to prevent overdischarge IP Rating: IP65 Refer: WLEX 100M Manufacturer: Denko .
